1983 RG250W Suzuki Gamma






1983—1984 RG250W Gamma specifications
Overall length:     2 050 mm (80.7 in.)
Overall width:    685 mm (27.0 in.)
Overall height:    1 220 mm (48.0 in.)
Wheelbase:    1 385 mm (54.5 in.)
Seat height:    785 mm (30.9 in.)
Ground clearance:    155 mm (6.1 in.)
Dry weight:    131 kg (289 lbs)
Engine type:     Liquid-cooled parallel twin 2-stroke
Intake system:    Piston and reed valve
Piston displacement:     247 cc (15.1 cu-in)
Bore x stroke:    54.0 x 54.0 mm (2.125 x 2.125 in.)
Compression ratio:    7.4 :1
Maximum power output:    46 hp (34,4 kW)/ 8.500 rpm
Maximum torque:    38.4 Nm (3.92 kg-m, 28.4 lb-ft)/ 8.000 rpm
Carburettor:    Mikuni VM28SS flat side x 2
Ignition:    Suzuki PEI (Pointless Electrical Ignition)
Lubrication:    Suzuki CCI
Clutch:    Wet multi-plate type
Transmission:    6-speed constant mesh
Gearshift pattern:    1-down, 5-up
Final drive:    #520 chain, 110 links, O-ring sealed
Front suspension:    Telescopic, coil spring, oil damped with anti-dive
Rear suspension:    Full Floater, gas/oil damped, spring pre-load fully adjustable
Front brake:    Double hydraulic disk
Rear brake:    Single hydraulic disk
Front tyre:    110/90-16 54S
Rear tyre:     110/80-18 58S
Fuel tank Capacity incl. reserve:    17 litre (4.5 US gal, 3.7 Imp gal)
Engine oil tank capacity:    1.2 litre (1.3 US gal, 1.1 Imp gal)
Battery:     12 V 18 kC (5 Ah)/10 HR
Headlight:     12 V 60/55 W
